OpenClaw 与 Nginx 集成教程

openclaw openclaw官方 1

OpenClaw 是一个开源的数据采集系统，Nginx 是高性能的 Web 服务器和反向代理,将它们集成可以提供：

OpenClaw 与 Nginx 集成教程-第1张图片-OpenClaw开源下载|官方OpenClaw下载

  • 负载均衡
  • SSL/TLS 加密
  • 静态文件服务
  • 访问控制
  • 性能优化

环境准备

安装 OpenClaw

# 克隆 OpenClaw 仓库
git clone https://github.com/openclaw-project/openclaw.git
cd openclaw
# 安装依赖
pip install -r requirements.txt
# 启动 OpenClaw (假设默认端口 8000)
python manage.py runserver 0.0.0.0:8000

安装 Nginx

# Ubuntu/Debian
sudo apt update
sudo apt install nginx
# CentOS/RHEL
sudo yum install epel-release
sudo yum install nginx
# 启动 Nginx
sudo systemctl start nginx
sudo systemctl enable nginx

基础配置

创建 Nginx 配置文件

sudo nano /etc/nginx/sites-available/openclaw.conf

基础反向代理配置

server {
    listen 80;
    server_name your-domain.com www.your-domain.com;
    location / {
        proxy_pass http://127.0.0.1:8000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        # WebSocket 支持（OpenClaw 使用）
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
    }
    # 静态文件缓存
    location /static/ {
        alias /path/to/openclaw/static/;
        expires 30d;
        add_header Cache-Control "public, immutable";
    }
    location /media/ {
        alias /path/to/openclaw/media/;
        expires 30d;
    }
}

高级配置选项

负载均衡配置

upstream openclaw_servers {
    # 配置多个 OpenClaw 实例
    server 127.0.0.1:8000 weight=3;
    server 127.0.0.1:8001 weight=2;
    server 127.0.0.1:8002 weight=1;
    # 健康检查
    least_conn;
    keepalive 32;
}
server {
    listen 80;
    location / {
        proxy_pass http://openclaw_servers;
        # ... 其他配置
    }
}

SSL/TLS 配置（使用 Let's Encrypt）

server {
    listen 443 ssl http2;
    server_name your-domain.com;
    ssl_certificate /etc/letsencrypt/live/your-domain.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/your-domain.com/privkey.pem;
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-RSA-AES256-GCM-SHA512:DHE-RSA-AES256-GCM-SHA512;
    ssl_prefer_server_ciphers off;
    # HSTS
    add_header Strict-Transport-Security "max-age=31536000" always;
    location / {
        proxy_pass http://127.0.0.1:8000;
        # ... 其他配置
    }
}
# HTTP 重定向到 HTTPS
server {
    listen 80;
    server_name your-domain.com;
    return 301 https://$server_name$request_uri;
}

访问限制配置

location /admin/ {
    proxy_pass http://127.0.0.1:8000;
    # IP 白名单
    allow 192.168.1.0/24;
    allow 10.0.0.0/8;
    deny all;
    # 基本认证
    auth_basic "Restricted Access";
    auth_basic_user_file /etc/nginx/.htpasswd;
}
# 限制请求速率
location /api/ {
    proxy_pass http://127.0.0.1:8000;
    # 限制每分钟 60 个请求
    limit_req zone=api burst=20 nodelay;
    limit_req_status 429;
}
# 在 http 块中添加
limit_req_zone $binary_remote_addr zone=api:10m rate=60r/m;

缓存配置

# 代理缓存
proxy_cache_path /var/cache/nginx levels=1:2 keys_zone=openclaw_cache:10m
                 max_size=1g inactive=60m use_temp_path=off;
server {
    location / {
        proxy_pass http://127.0.0.1:8000;
        # 启用缓存
        proxy_cache openclaw_cache;
        proxy_cache_key "$scheme$request_method$host$request_uri";
        proxy_cache_valid 200 302 10m;
        proxy_cache_valid 404 1m;
        # 缓存绕过
        proxy_cache_bypass $http_cache_control;
        add_header X-Cache-Status $upstream_cache_status;
    }
}

性能优化配置

缓冲区优化

location / {
    proxy_pass http://127.0.0.1:8000;
    # 缓冲区设置
    proxy_buffer_size 128k;
    proxy_buffers 4 256k;
    proxy_busy_buffers_size 256k;
    # 超时设置
    proxy_connect_timeout 90;
    proxy_send_timeout 90;
    proxy_read_timeout 90;
    # 启用压缩
    gzip on;
    gzip_vary on;
    gzip_min_length 1024;
    gzip_types text/plain text/css application/json application/javascript;
}

连接池配置

upstream openclaw_backend {
    server 127.0.0.1:8000;
    # 连接池
    keepalive 32;
    keepalive_requests 1000;
    keepalive_timeout 60s;
}
location / {
    proxy_pass http://openclaw_backend;
    proxy_http_version 1.1;
    proxy_set_header Connection "";
}

日志配置

自定义日志格式

# 在 http 块中添加
log_format openclaw_log '$remote_addr - $remote_user [$time_local] '
                       '"$request" $status $body_bytes_sent '
                       '"$http_referer" "$http_user_agent" '
                       '"$upstream_addr" $request_time';
server {
    access_log /var/log/nginx/openclaw_access.log openclaw_log;
    error_log /var/log/nginx/openclaw_error.log warn;
    location / {
        proxy_pass http://127.0.0.1:8000;
        # ... 其他配置
    }
}

监控配置

Nginx 状态页面

location /nginx_status {
    stub_status on;
    access_log off;
    allow 127.0.0.1;
    deny all;
}

健康检查端点

location /health {
    proxy_pass http://127.0.0.1:8000/health;
    access_log off;
    # 健康检查设置
    proxy_next_upstream error timeout http_500 http_502 http_503 http_504;
    proxy_connect_timeout 5s;
    proxy_read_timeout 5s;
}

部署和测试

启用配置

# 创建符号链接
sudo ln -s /etc/nginx/sites-available/openclaw.conf /etc/nginx/sites-enabled/
# 测试配置
sudo nginx -t
# 重启 Nginx
sudo systemctl reload nginx

测试命令

# 测试连接
curl -I http://your-domain.com
# 测试负载均衡
for i in {1..10}; do curl http://your-domain.com/api/status; done
# 查看 Nginx 状态
curl http://localhost/nginx_status
# 监控日志
sudo tail -f /var/log/nginx/openclaw_access.log

故障排除

常见问题及解决方案：

  1. 502 Bad Gateway

    # 检查 OpenClaw 是否运行
ps aux | grep openclaw
# 检查端口
netstat -tlnp | grep :8000
# 检查 Nginx 错误日志
tail -f /var/log/nginx/error.log

  2. 性能问题

    # 检查系统资源
top
htop
# 检查连接数
ss -tan | grep ESTAB | wc -l
# 调整系统参数
sysctl -w net.core.somaxconn=65535
sysctl -w net.ipv4.tcp_max_syn_backlog=65535

  3. 权限问题

    # 确保 Nginx 用户有权限访问文件
sudo chown -R www-data:www-data /path/to/openclaw/static/
sudo chmod -R 755 /path/to/openclaw/static/

安全建议

  1. 定期更新

    sudo apt update && sudo apt upgrade nginx

  2. 防火墙配置

    # 只开放必要端口
sudo ufw allow 80/tcp
sudo ufw allow 443/tcp
sudo ufw enable

  3. 安全头配置

    add_header X-Frame-Options "SAMEORIGIN" always;
add_header X-Content-Type-Options "nosniff" always;
add_header X-XSS-Protection "1; mode=block" always;
add_header Referrer-Policy "strict-origin-when-cross-origin" always;

这个配置为 OpenClaw 提供了一个生产级的 Nginx 反向代理设置，根据实际需求调整参数,特别是缓存策略和安全设置。
